Edelbrock Carburetor, AVS2 Series, 4-Barrel, 650 CFM, Square Bore, Manual Choke, Mechanical Secondary, Single Inlet, Satin

The Edelbrock AVS2 Series #1905 is a satin-finished carburetor with manual choke that is designed and calibrated for optimum street performance in engines that require 650 CFM of air-fuel flow. The AVS2 is a perfect four-barrel replacement or upgrade that features annular flow primary boosters with a new calibration for improved off-idle and cruising performance. The annular flow booster design delivers improved fuel atomization to eliminate flat spots that may be encountered as the carburetor transitions from idle to full throttle. Each annular flow booster features eight equally spaced orifices to improve fuel metering from idle to the main circuit. The improved flow metering makes this carburetor ideal for use with a wide variety of small- and big-block engines with either dual- or single-plane intake manifolds. The Edelbrock AVS2 #1905 includes both timed and full vacuum ports for ignition advance. It comes with .101 primary and .098 secondary metering jets, .070 x .037 metering rods, and orange (5" Hg) step-up spring.
